Request a quote on stock# 4176| Specification | Description |
|---|---|
| Clamp Force: | 102 US Tons |
| Shot Size: | 3.42 Oz/30 mm |
| Platen Size: | 56.2" x 26.5" |
| Tie Bar Spacing: | 47.4" x 14.7" |
| Min Mold Ht: | 11.81" |
| Max Weight Movable Mold Half: | 882 lbs |
| Clamp daylight Max: | 23.62" |
| Ejector Stroke: | 6.89" |
| Rotary table dia: | 1200 mm/47.24" with 2 Position |
| Motor size | 30 HP |
| Voltage: | 460 |
| Dimensions L x W x H: | 171.65" x 67.64" x Confirm |
| Weight: | 20,283 lbs |
