| Specification | Description |
|---|---|
| Clamp Force: | 85 US Tons |
| Shot Size: | 5Oz/35 mm |
| Platen Size: | 21.65" x 13.23" |
| Tie Bar Spacing: | NA |
| Min/Max Daylight: | 11.02" - 22.83" |
| Min/Max Mold Ht: | 11.02" - NA |
| Clamp Stroke: | 11.81" |
| Ejector Stroke: | 5" (penetration 2") |
| Ejector force: | 1.3 US Tons |
| Rotary table dia: | 38.39" |
| Mold pitch cir dia: | 20.87 |
| Voltage: | 230 |
| Dimensions: | 129" x 106" x 118" |
| Weight: | 17,020 lbs |
