| Specification | Description |
|---|---|
| Clamp Force: | 200 US Tons |
| Shot Size: | 12.7 Oz/50 mm |
| Platen Size: | 37.4" x 29.53" |
| Tie Bar Spacing: | NA |
| Clamp Stroke: | 17.72" |
| Max Daylight: | 37.4" |
| Min/Max Mold Ht: | 7.87" - 19.69" |
| Free drop area under clamo: | 21.85"" |
| Max mold weight: | 2,646 lbs on moving side |
| Ejector Stroke: | 5.91" |
| Voltage: | 460 |
| Dimensions: | 249"L x 72" x 88"H |
| Weight: | 35,260 lbs |
