Request a quote on stock# 3477| Specification | Description |
|---|---|
| Capacity | 7.5Ton @ 50F LWT & 95F ambient |
| Air-Cooled Condensor Style: | Fan |
| CFM x 1000: | 10 @ 95 F Ambient |
| Compressor | Scroll |
| Pump size | 2 HP SS - 18 GPM @ 50 PSI |
| Connection Sizes: | 1 - 1/4" To and From 1/2" Make |
| Tank | 25 Gallon non-ferous with Lid |
| Control | CF-1 Microprocessor |
| Full load amps - Voltage | 24 @ 460V |
| Dimensions | 60"H x 34"W x 56"L |
| Weight | 1250 lbs |
| Location | Greenwood, IN |
| Warranty | 1 Year parts & labor |
